Double Deck XYEK500,XYEK508 Good Quality Pcb Screw Terminal Block 5.0mm 5.08 Pitch Replace Phoenix DG128-5.0 Manufacturer

Miejsce pochodzenia Chiny
Nazwa handlowa Xinlaiya
Orzecznictwo -
Numer modelu XYEK500-5.0 XYEK508-5.08
Minimalne zamówienie 1
Cena USD1/PC
Szczegóły pakowania Oryginalny
Czas dostawy w magazynie
Zasady płatności L/C, D/A, D/P, T/T, Western Union
Możliwość Supply 1000
Szczegóły Produktu
gwarancja 1 rok Polacy 2P, 3P-24P
Standard UL, IEC Wytrzymuje napięcie AC2000V/min
Zostaw wiadomość
opis produktu

Double Deck XYEK500,XYEK508 Good Quality Pcb Screw Terminal Block 5.0mm 5.08 Pitch Replace Phoenix DG128-5.0 Manufacturer 0Double Deck XYEK500,XYEK508 Good Quality Pcb Screw Terminal Block 5.0mm 5.08 Pitch Replace Phoenix DG128-5.0 Manufacturer 1Double Deck XYEK500,XYEK508 Good Quality Pcb Screw Terminal Block 5.0mm 5.08 Pitch Replace Phoenix DG128-5.0 Manufacturer 2Double Deck XYEK500,XYEK508 Good Quality Pcb Screw Terminal Block 5.0mm 5.08 Pitch Replace Phoenix DG128-5.0 Manufacturer 3



Conductor Size
12 - 24AWG
Connection Method
Screw Connection
Type
PCB
Number of Pole
2P-24P
Contact Material
Brass
Place of Origin
Zhejiang, China
Model Number
XYEK500-5.0 XYEK508-5.08
Brand Name
Xinlaiya
Poles
2P, 3P-24P
Pitch
5.0mm 5.08mm
Standard
UL , IEC
Voltage Rating
300V/250V
Current Rating
15A-18A
Wire range
24-12AWG/2.5m㎡
Withstanding Voltage
AC2000V/Min
Ambient temperature
-40 centigrade~+105 centigrade
Pin header
Brass, Tin Plated
Housing
PA66.UL94V-0
