Fluke VT06 Visual IR Thermometer Infrared Thermometer VT06

  • Fluke VT06 Visual IR Thermometer Infrared Thermometer VT06
  • Fluke VT06 Visual IR Thermometer Infrared Thermometer VT06
  • Fluke VT06 Visual IR Thermometer Infrared Thermometer VT06
  • Fluke VT06 Visual IR Thermometer Infrared Thermometer VT06
Miejsce pochodzenia Chiny
Nazwa handlowa fluke
Orzecznictwo /
Numer modelu VT06
Minimalne zamówienie 1 szt
Cena USD 410/PC
Szczegóły pakowania Oryginalne opakowanie
Czas dostawy 1-3 dni robocze
Zasady płatności T/T
Możliwość Supply 1000pc/miesiąc

Skontaktuj się ze mną, aby uzyskać bezpłatne próbki i kupony.

Whatsapp:0086 18588475571

wechat: 0086 18588475571

Skype: sales10@aixton.com

W razie jakichkolwiek wątpliwości zapewniamy całodobową pomoc online.

x
Szczegóły Produktu
Rozdzielczość w podczerwieni 120 × 90 Pasmo częstotliwości podczerwieni 7,5 ~ 14 μm (długa fala)
Ramka klatek 9 Hz Wrażliwość termiczna/NETD <60 mk
Rozkład przestrzenny 7,6 mrada
Zostaw wiadomość
opis produktu

Fluke VT06 Visual IR thermometer

Model#: Fluke VT06
  • Fluke VT06 Visual IR Thermometer Infrared Thermometer VT06 0
  • Fluke VT06 Visual IR Thermometer Infrared Thermometer VT06 1
  • Fluke VT06 Visual IR Thermometer Infrared Thermometer VT06 2
  • Fluke VT06 Visual IR Thermometer Infrared Thermometer VT06 3

Key features

  • 120 x 90 resolution for more details
  • Wide temperature range, -20°C to 400°C
  • IP65 rated for dust and water proof, 2m drop test, suitable for harsh industrial environments
  • Quickly locate the measured target with built-in laser pointer
  • 2 hours charging time, 8 hours battery life
  • Single-level menu interface, Open-and-View





Product overview: Fluke VT06 Visual IR thermometer

Fluke VT series is built with legendary Fluke ruggedness and quality. With compact design and upgraded function, the temperature measurement is visualized, so that you can obtain a clear and accurate infrared thermal image.


Specifications: Fluke VT06 Visual IR thermometer

Thermal image and optics VT08 VT06
Infrared resolution 120×90
IR frequency band 7.5~14 μm(long wave)
Frame rate 9 Hz
Thermal sensitivity/NETD <60 mk
Field of view (H x V) 50° x 37.5°
Spatial resolution 7.6 mrad
Focus system Focus free
Minimum focusing distance 0.5 m (19.7 in)
Visible light
Visible resolution 320×240 NA
Visible FOV (H x V) 53° x 41° NA
Image display and storage
Image mode Thermal image
Visible image
PIP		 Thermal image
Palettes Ironbow, Blue-Red, High-Contrast, Amber, Hot Metal, Grayscale
Internal storage >28GB (>100000 images)
*14GB Internal Storage for VT06/VT08 manufactured before 6 Aug 2022.
File format JPEG compression format (.jpg)
PIP mode Yes No
Temperature measurement
Temperature range -20 °C to 400 °C
[-4 °F to 752 °F] (not specified for below -10 °C)
Temperature accuracy ±2°C or 2% @ 23°C±5°C, whichever is greater
Emissivity Adjustable
Background temperature compensation Yes
Auto high-/low-temperature capture Yes
Center point temperature Yes
Alarm Maximum/minimum temperature alarm in full screen
Interface and lens
Visible lens Yes No
Flashlight Yes No
Infrared lens Yes
Laser sighting Yes
Type-C interface Yes
TF card slot No
Tripod interface Yes
Mobile App No
Power system
Battery type Rechargeable Li-ion battery, unremovable
Battery operation time ≥5 hrs (VT08)
≥8 hrs (VT06)
Actual battery life depends on environment and settings
Charging Time <2.5 hrs to full
Battery charging temperature 0 °C to 45 °C
Battery charging system Charge in the machine (the battery is not removable)
AC adapter Include power supply, universal adapter
Output: 5 VDC, 2 A
Power saving mode Yes
Environmental specifications
Operating temperature -10 °C to 50 °C
Storage temperature -40 °C to 70 °C
Operating altitude 2000 m (1.24 mi)
Storage altitude 12 000 m (7.5 mi)
Others
Warranty 1 year
Standard accessories Wrist strap, quick reference guide, charger + adapter, Type-C data cable, data-downloading card
Display 6.096 cm (2.4-inch) LCD
Language English
Size 20.4 cm x 6.6 cm x 7.6 cm
Weight 0.36 kg 0.35 kg
Relative humidity ≤90%, non-condensing
Safety
Safety standards IEC 61010-1: Pollution Degree 2
Laser IEC 60825-1: Class 2, 650 nm, <1 mW
Battery IEC 62133-2, UN 38.3
Protection class IEC 60529: IP65 (with Type-C port closed)
Drop test 2 m
Electromagnetic Compatibility (EMC)
International IEC 61326-1: Industrial Electromagnetic Environment
CISPR 11: Group 1, Class A
